WebRTC Architecture empowers businesses to deliver low-latency and interactive video, voice, and data-sharing solutions for real-time experiences. If you’re a tech leader, startup owner, or decision-maker, understanding its architecture is key to planning your next big communication platform. This blog provides actionable insights into its core components, architectural patterns, and scalability strategies to design robust WebRTC systems that balance cost and performance.
Table of Content
Do you know how communication apps like Zoom or WhatsApp manage to connect people instantly, no matter where they are? Well, it’s because they have built a seamless WebRTC architecture that not just connects users but also consistently delivers high-quality interactions, regardless of network or device.
For businesses aiming to create similar interactive real-time communication platforms, WebRTC is the conductor that bridges users in real-time, ensuring flawless performance of real-time audio, video, and data exchange.
According to Fortune Business Insights, the global WebRTC market is projected to reach USD 94.07 billion by 2032 and grow at an impressive 38.3% CAGR, so its importance can’t be overstated.
This blog dives into how WebRTC works, why it’s critical for real-time solutions, and how you can harness its power to create impactful communication experiences for your users. Whether you’re a tech leader or startup founder, this is your guide to building a solution that stands out.
Real-time communication (RTC) enables users to exchange information instantly without delays. It takes place between devices and people by sending and receiving messages or actions. RTC secures the sharing of data, audio, and video with a collection of APIs and protocols.
Since it is different from emails, it can be easily integrated into many business settings. Some everyday examples include phone and video calls, live streaming apps, and robotic communications.
RTC is important because modern business communication systems need to provide elevated user experiences. With immediate two-way communication, RTC increases collaboration between teams and clients and, hence, enhances productivity.
In any industry, whether it is healthcare, education, or entertainment, business scalability is the defining factor for success. Moreover, with the growing demand for multi-platform user experiences, having a reliable real-time communication platform becomes essential.
Here’s how building a robust and scalable WebRTC architecture will empower your business with real-time communications:
Communication can’t always follow the top-down model. With the fluidity of information in business today, leaders need to be masterful listeners; they need to be able to receive as well as send.
WebRTC is designed to enable direct communication between browsers. It standardizes the communication process with a set of classes and methods. Each WebRTC application requires a basic infrastructure on the server side to exchange signaling messages between participants.
Additionally, the browsers provide easy and secure hardware access to stream microphone(s), camera(s), and screen(s). However, the faster this technology is, the more complex its architecture.
WebRTC isn’t built on a single methodology, like WebSockets or REST. Hence, it’s important to know how WebRTC architecture works to understand how it operates.
In today’s digital world, real-time means having a streaming latency of less than one second. WebRTC works on the following core principles that make it highly effective for building real-time communication platforms:
A P2P connection and signaling are the two crucial components that make WebRTC architecture more popular than traditional technologies. Others include the signaling layer, media encoding & decoding layer, and servers.
Let’s dive deeper into these and understand how the media, sessions, and servers are connected:
The signaling layer is the server that helps track events once the call is initiated. It tracks the persons who join, leave, create, or dispose of a connection. The WebRTC signaling architecture facilitates the connection between two or more peers who want to connect at a time.
WebRTC is based on P2P architecture, which doesn’t require a middleman to transfer data between participants as they are responsible for themselves. They are also geographically close, which decreases the distance for data to travel. It is one of the key components of WebRTC, forming the communication layer.
WebRTC utilizes codecs (coding and decoding techniques) and hardware acceleration to compress and decompress digital media files and make HD videos interactive. The entire mechanism is called WebRTC-encoded transforms, which sends, handles, accepts, configures, and modifies data chunks and frames over the network.
Once initiated, SDP extracts all the information related to how a connection is established and the exchange of information takes place. This protocol includes all the details about the peer, like the agent in use, supported hardware, the type of media exchange, etc., in a bi-directional response (whoever initiates, the outcome is the same).
Network Address Translation (NAT) Traversal is a proxy through which most global networks pass, even though they are directly connected. Different types of NAT configurations include Normal (full cone) NAT, Symmetric NAT, Restricted Cone NAT, and Port-restricted Cone NAT.
When passed over a router, all of these transfer a machine’s private IP/port to a different port. When they go through a proxy, the parties might face some complications. For this, Session Traversal Utils for NAT (STUN) server URLs offer standardized methods to establish connections.
Build a high-performing WebRTC solution and overcome latency and scalability issues.
WebRTC architecture facilitates real-time communication through an efficient and modular workflow. Here’s a simplified step-by-step breakdown:
The signaling process is initiated when any two clients exchange data or information to establish a connection by loading a WebRTC application. These clients could be browsers or apps that want to establish a connection by exchanging signal information.
The second step involves a signaling server exchanging SDP messages and Interactive Connectivity Establishment (ICE) candidates using Socket.io or Websockets. SDP messages contain media formats and codecs, and ICE dictates the best path between NATs and firewalls.
The third step is setting up a media stream using ICE to determine a direct P2P or TURN server connection path for a secured DTLS-SRTP encryption. The quality of media exchange is adjusted using adaptive bitrate based on network conditions to ensure a smooth experience.
The fourth step defines data transmission by adding support for data channels to exchange non-media data like chat messages or files. If P2P isn’t an option, a TURN server relays data despite complex NAT setups.
The last step is to optimize and monitor media using servers like SFU for advanced features like multi-user conferencing and quality enhancements. Additionally, monitoring tools analyze latency, jitter, and bitrate to optimize performance.
While planning a WebRTC architecture, it’s essential to consider the decisions that significantly impact the decisions you will take. It includes the capabilities to offer, type of user experience, deployment, and efforts to maintain. Here are some of them:
It is important to consider the type of architecture you need depending on the team size. If you have a small team, P2P is ideal. If you have large events to stream, choose SFU. Hence, choose an architecture that can accommodate the user’s needs for building real-time communication platforms.
Ensure that the architecture you choose is secured, private, and encrypted for maximum security. Make sure you are choosing a secure protocol like Secure Real-time Transport Protocol (SRTP).
Key exchange mechanisms like Multimedia Internet KEYing (MIKEY), Zimmermann Real-time Transport Protocol (ZRTP), and Simplified Data Encryption Standard (SDES) should also be considered.
Budget is critical for optimizing bandwidth usage. Implement only necessary features and use open-source signaling and media servers and frameworks like Janus and Mediasoup. You can also optimize TURN servers using them as a fallback for NAT traversal.
Make sure the team you are working with is proficient in APIs and protocols like SDP and has a deep understanding of WebRTC signaling architecture and servers. They should also be skilled in network configuration, have expertise in media processing codecs, and be knowledgeable in implementing secured encryption.
Every WebRTC solution is based on a type of architecture. They work differently, but the process of sending and receiving audio and video streams over the Internet remains the same.
All the participants involved in the conferencing should be able to see or hear each other’s audio and video. Depending on the needs, you can choose the preferred type of architecture or use a hybrid approach. Let’s discuss the three main types:
Under the modular architecture, the WebRTC system is divided into interchangeable and independent modules. Each module has a separate functionality, such as signaling, session management, media processing, etc.
This type of architecture is ideal for gaming and live-streaming applications.
| Pros and Cons |
|---|
|
Mesh networks are also popularly known as P2P application architecture. This concept involves a direct connection between each individual (peer) in a conference broadcasting audio and video. When intermediate media servers are absent, the mesh architecture facilitates privacy through end-to-end encryption.
Hence, P2P calls are only suitable for 1:1 calls where only 2 peers are involved since they have to establish a connection only once.
| Pros and Cons |
|---|
|
SFU is a preferred option for modern video streaming & conferencing applications and often utilizes the simulcast technique. In this architecture, media servers act as intermediaries that receive the incoming streams and distribute them among participants based on their Internet speeds.
Multiple streams are transmitted at varying qualities before SFU selects the most appropriate quality to forward. This means participants with lower bandwidth will receive a lower-quality stream and vice versa.
| Pros and Cons |
|---|
|
Choosing the right WebRTC architecture depends on your unique needs. You should understand how many participants your organization has, whether you need high or low latency, what type of security you need, and what your budget and the costs of features you need. Here are the essential steps:
The first step is to identify the type of WebRTC application you need to develop. Do you want a live-streaming app or a video conferencing app? Based on this, the number of participants and the scope of scale should be decided.
Next, analyze the current state of communication and the challenges it poses. Are you facing high or low latency, media quality, or compatibility issues? Prioritize the critical issues and choose an architecture that aligns with your bandwidth requirements.
It’s best to consult with expert WebRTC development professionals to help you design a custom solution without sacrificing quality.
Thirdly, evaluate the tools and technologies you need. These include media server handling tools like Janus and Jitsi, network performance monitoring technologies like Callstats.io and InspectRTC, frameworks, codecs, and APIs for third-party integrations.
Ensure that your chosen architecture supports encryption with DTLS-SRTP protocols. Additionally, calculate your available server capacity and budget to optimize your WebRTC signaling architecture for best performance.
The last step is to test your architecture before implementing it and plan for future growth with AI-powered communication and 5G. Conduct pilot tests under real-world scenarios and refine them based on the metrics and feedback.
Let us help you build a future-ready WebRTC architecture integrated with AI and 5G.
Being an open-source technology, WebRTC is a versatile platform that is widely supported across major browsers. However, even though its architecture has built-in security and efficient codecs, its implementation is challenging. Let’s understand how:
Delayed responses in streams reduce the quality and misalign them. If the transmission times are longer, the risks of data packet losses are increased.
Solution: Use Forward Error Correction (FEC) algorithms and set Quality of Service (QoS) flags to minimize the impact during high latency.
Different browsers handle WebRTC differently. This can lead to bandwidth constraints and impact the quality of calls in terms of lags and drops.
Solution: Utilize adaptive bitrate streaming with codecs like VP8 and Opus to maintain consistent quality across browsers and devices.
In unstable networks, retransmitting the lost data packets can become a challenge. This would lead to inefficient audio and video quality since it doesn’t define a signaling protocol.
Solution: Use custom implementations to initiate sessions with established frameworks like Websockets and monitor metrics like packet loss and latency.
Real-time communication provides businesses with a digital compass. It allows them to keep their teams and customers always in the loop, regardless of where they reside. Here are some best practices they can adopt:
Signal automation using AI-powered communication models helps detect and filter out background noise. Using AI with ML can help maintain audio and video quality during fluctuations.
How to Apply: Use WebRTC’s built-in audio processing tools and NVIDIA’s AI-based noise suppression tools. Based on the network or device, selective forwarding units (SFUs) and multipoint control units (MCUs) are used to forward media streams and centralize signals.
Monitoring media streams helps ensure that the audio and video quality is consistently high. Hence, they need to be collected directly from user devices to provide a better communication session and user experience.
How to Apply: Use a WebRTC monitoring solution to troubleshoot and track metrics like frame rates, bitrates, and resolutions to improve data quality during transmission.
Using standardized tools and libraries across teams prevents unnecessary delays, as teams can recognize and address problems faster. A single-space platform where the communication resources are housed encourages cross-team collaboration.
How to Apply: Use popular frameworks like SimpleWebRTC, which have straightforward APIs coupled with data and screen-sharing features. Similarly, libraries like PeerJS and Socket.io simplify establishing P2P communication with an event-driven architecture.
Is your business looking to overcome communication delays and deliver seamless real-time experiences? A robust WebRTC architecture will help you build a reliable, high-quality communication solution.
Today, your business needs scalable and platform-compatible WebRTC applications. Partner with a WebRTC development company to deliver exceptional communication experiences.
Contact our experts at Moon Technolabs to get the following:
With its low latency, secure, and adaptive features, WebRTC ensures smooth interactions, even in challenging network conditions. Furthermore, future advancements like AI-powered communication enhancements and 5G integration solidify its importance.
